Speed your DAF/DAFF conversion efforts and enjoy significant energy cost savings and 2x performance improvement

Suspended Air® Flotation (SAF®) Conversions offer a fast and effective way to upgrade traditional flotation systems. By simply adding a SAF® Generator and ClearMixer®, facilities can achieve cleaner effluent, higher flow capacity, and increased solids loading. The process also produces drier float and significantly reduces energy, maintenance, and operating costs. Most conversions can be completed within hours, minimizing downtime and maximizing performance.

Applications

Algae Control in Reservoirs & Lagoons
Biosolids Management
Collection System Overflow (I&I)
Drinking Water Treatment / NSF Certified
Enhanced Primary Clarification
Filter Backwash Recovery
Landfill Leachate Treatment
Municipal Wastewater Plants (WAS / Primary / Secondary)
Reclaimed Water / Title 22 Applications
Remote or Decentralized Facilities
Stormwater Treatment
Surface Water Pretreatment
Water Reuse / Recycle Facilities
Agriculture
Automotive
Breweries & Wineries
Chemical
Dairy
Food & Beverage
Landfills
Meat & Poultry
Metal Finishing / Plating
Mining & Minerals
Oil & Gas / Petrochemical
Paints & Coatings
Paper & Pulp
Pharmaceuticals
Plastics & Injection Molding
Power Generation
Steel Manufacturing
Textiles & Dyeing

Benefits

Benefits
Suspended Air Flotation (SAF®) is an advanced water treatment technology that offers highly efficient removal of suspended solids. SAF creates optimal results with reduced OPEX.
- Lower Energy Consumption
- Compact Footprint
- Plug-and-Play
- Operator Friendly
- Low Maintenance
- Fast Start Up & Shut Down
- Resilient to Load Changes
- Lower Chemical Use
- Manages Changing Water Conditions & Upsets
- Batch Processing
Design Features
- Suspended Air® Flotation Generator – Core technology for high-efficiency solids and oil removal
- ClearFloater® – Flotation tank for separation and collection
- ClearMixer® – Integrates froth with effluent to aid in flotation
- Flock Tubes – Facilitates mixing and reaction of polymers, coagulants, and pH agents
- Control Panel and Automation – PLC-based system for streamlined operation and integration
Secondary SAF® Conversion
DAF specifications:
- 216 ft² of surface area
- At 1.8 MGD before SAF®, DAF handled 1,500 mg/L influent solids (3-4 lbs/hr/ft²)
After SAF®
- Same float cell handles 3,500 mg/L (15 lbs/hr/ft²) with no carry over. Average effluent TSS = 15mg/L
- Treats 5.4 MGD after conversion
All that is required is a SAF® Generator & ClearMixer®. Pressurization, recycle system, and lamella plates are removed.
